remove .hex, .PNG, .jpg

keyboards/ergodox/keymaps/alexjj/readme.md

@@ -22,7 +22,7 @@ the 1st layer - in case of fat fingers.
 Layout
 -------

-![Layout](rl-layout.jpg "Isn't it lovely")
+![Layout](https://i.imgur.com/4bDwHLS.jpg "Isn't it lovely")

 ### Base Layer


keyboards/ergodox/keymaps/colemak_programmer/readme.md

@@ -19,5 +19,5 @@ I came to this layout after several iterations. It is not the ultimate best ergo

 Alternatively view the [graphical creator version](http://configure.ergodox-ez.com/keyboard_layouts/kmevwm/edit) but beware it is not the same due to the creator limitations.

-![Default](colemak_programmer_001.jpg)
-![Default](colemak_programmer_002.jpg)
+![Default](https://i.imgur.com/BCJEoKw.jpg)
+![Default](https://i.imgur.com/0P1jBph.jpg)

keyboards/ergodox/keymaps/supercoder/readme.md

@@ -1,7 +1,7 @@
 SuperCoder 2000 layout for the ErgoDox
 ==================================================

-![SuperCoder 2000](images/supercoder_2000.jpg)
+![SuperCoder 2000](https://i.imgur.com/6dcU9VY.jpg)

 Ever found yourself in need of entering binary codes rapidly? Ever wanted to use
 all ten fingers to do so? Ever felt your SuperCoder 2000 too limiting, by only

keyboards/gh60/keymaps/robotmaxtron/readme.md

@@ -10,7 +10,7 @@ For the full Quantum feature list, see the parent readme.md.
 * Neopixel/WS2812 RGB Underglow Support

 ## Reference Images
-![Wiring Refererence] (WS2812-wiring.jpg)
+![Wiring Refererence](https://i.imgur.com/BkJ39JD.jpg)

 ### Additional Credits
 Keymap has been based on various keymaps available from the QMK Repo for the GH60-SATAN and KC60 keyboards.

keyboards/gh60/keymaps/unxmaal/README.md

@@ -18,3 +18,5 @@ For the full Quantum feature list, see the parent readme.md.

 ### Additional Credits
 Keymap has been based on various keymaps available from the QMK Repo for the GH60-SATAN and KC60 keyboards.
+
+![wiring](https://i.imgur.com/8b8T1fQ.jpg)

keyboards/gh60/readme.md

@@ -1,6 +1,6 @@
 ## gh60 Rev C keyboard firmware

-![gh60 Rev C PCB](gh60revc.jpg)
+![gh60 Rev C PCB](https://i.imgur.com/FejpoNF.jpg)

     /* Column pin configuration
     * col: 0   1   2   3   4   5   6   7   8   9   10  11  12  13

keyboards/handwired/minorca/keymaps/rgb/readme.md

@@ -1,6 +1,6 @@
 #RGB backlight for MinOrca

-![wiring](example.jpg)
+![wiring](https://i.imgur.com/jyYyiSS.jpg)

 Example of adding WS2812b LEDs to a MinOrca.

@@ -21,5 +21,5 @@ Example wiring:

 WS2812 data pin is connected to D5

-![wiring](wiring1.jpg)
-![wiring closeup](wiring2.jpg)
+![wiring](https://i.imgur.com/CFBf71F.jpg)
+![wiring closeup](https://i.imgur.com/VJogRoj.jpg)

keyboards/kc60/keymaps/ws2812/readme.md

@@ -1,21 +1,21 @@
 KC60 with WS2812 RGB Underglow
 ======================

-![Image of KC60 with RGB Underglow](ws2812_example.jpg)
+![Image of KC60 with RGB Underglow](https://i.imgur.com/LpUkVqG.jpg)

 ## Quantum MK Firmware
 For the full Quantum feature list, see [the parent readme.md](/readme.md).

 ## WS2812 Support
-By default, it is now setup for 16 LEDs on the PF5 breakout pin. See [included image](ws2812_wiring.jpg) for wiring reference.
+By default, it is now setup for 16 LEDs on the PF5 breakout pin. See [included image](https://i.imgur.com/TcKL2Sn.jpg) for wiring reference.

 ### Build
 To build this keymap with WS2812 enabled, simply run `make KEYMAP=ws2812`.

 ### Reference Images
-![Wiring Reference](ws2812_wiring.jpg)
-![RGB Strip turned on](ws2812_underside-lit.jpg)
-![RGB Strip turned off](ws2812_underside.jpg)
+![Wiring Reference](https://i.imgur.com/TcKL2Sn.jpg)
+![RGB Strip turned on](https://i.imgur.com/21POu4l.jpg)
+![RGB Strip turned off](https://i.imgur.com/vAOLYNV.jpg)

 ### Additional Credits
 Keymap based on work by [TerryMatthews](https://github.com/TerryMathews) for GH60 Satan.

keyboards/kinesis/alvicstep/docs/readme.txt

@@ -24,6 +24,11 @@ PB7	28	c8					RA		PU		PD	n	m	,<		.>	/?	RS
 schematic:
 https://i.imgur.com/cCmWH4E.png

+photos:
+https://i.imgur.com/xiaE4tk.jpg
+https://i.imgur.com/PQ1y2vS.jpg
+https://i.imgur.com/OoQvgfA.jpg
+
 40 pin connector

    DL2	1	40	VCC

keyboards/kinesis/stapelberg/readme.md

@@ -53,3 +53,6 @@ This keymap contains a dvorak implementation as well as media and symbol layers.

 Run `make dvorak` while in the `kinesis_stapelberg` working directory.

+![controller board](https://i.imgur.com/2ZPMwvZ.jpg)
+![exterior reset](https://i.imgur.com/JNoxI40.jpg)
+![teensy detail](https://i.imgur.com/HrkGUjc.jpg)

keyboards/phantom/pinout.txt

@@ -1 +1 @@
-For WS2812B LED strip support, connect DIN from strip to PE2 on Teensy (see reference image pinout.jpg)
+For WS2812B LED strip support, connect DIN from strip to PE2 on Teensy (see reference image https://i.imgur.com/aDfNoHT.jpg)

keyboards/planck/keymaps/ab/readme.md

@@ -2,7 +2,7 @@
 A practical keymap that emulates standard QWERTY keyboard for Planck. Once you get comfortable with this keymap, you may fork and customize it for your own needs.

 ![Layout](https://i.imgur.com/xnlaiZd.png "Practical Keymap")
-![Photo](keyboard-photo.jpg "Planck Keyboard")
+![Photo](https://i.imgur.com/1kQPbLv.jpg "Planck Keyboard")

 * Online keyboard layout editor: http://www.keyboard-layout-editor.com/#/gists/bda299020baaafe6a2a4a82e615e3cfc


keyboards/planck/keymaps/dshields/readme.md

@@ -8,5 +8,5 @@ one-shot layers, tap-dance keys and dynamic macros.
 Layout
 -------

-![Layout](keyboard-layout.jpg "Keyboard Layout")
+![Layout](https://i.imgur.com/vZR3c8m.jpg "Keyboard Layout")


keyboards/planck/keymaps/espynn/readme.md

@@ -3,7 +3,7 @@ Created by James Folkert: https://twitter.com/trekloFsemaJ
 Added several custom functions to the keymap from the "ab" map. Special thanks to "mollat" for demonstration of macros in their keymap.c


-![Layout](keyboard-layout.jpg "Practical Keymap")
+![Layout](https://i.imgur.com/PEI4eva.jpg "Practical Keymap")


 * Online keyboard layout editor: http://www.keyboard-layout-editor.com/

keyboards/planck/keymaps/jacob/readme.md

@@ -1 +1,3 @@
-Focus of this particular keymap is to enable easy transition from more traditional keyboards to OLKB Planck.
+Focus of this particular keymap is to enable easy transition from more traditional keyboards to OLKB Planck.
+
+![layout](https://i.imgur.com/YG7xVp8.png)

keyboards/planck/keymaps/yale/readme.md

@@ -0,0 +1 @@
+![pic](https://i.imgur.com/OmARVcw.jpg)

keyboards/planck/keymaps/yang/readme.md

@@ -0,0 +1,2 @@
+![rgb](https://i.imgur.com/97E6aSo.jpg)
+![wiring](https://i.imgur.com/yL2ybk6.jpg)

keyboards/s60_x/keymaps/ansi_qwertz/readme.md

@@ -77,17 +77,17 @@ If you don't want this to be the case, uncomment the following line in `keymap.c
 The base layer is shown here for ANSI keysm, HHKB-style right shift and split backspace. If you use a 2U backspace key there, `Del` will not be available.
 Again, the Y and Z keys are swapped, so you get the QWERTZ-positions of Y and Z when using the US-International layout.

-![base_layer](docs/base_layer.PNG)
+![base_layer](https://i.imgur.com/gDvJT2n.png)

 ###1.1 Gaming layer
 To turn this layer on, please use the combination `Fn+RShift`, not `Space+RShift`. If you do the latter, the Function layer will become stuck. You can press `Fn` once to unstick it if this happens to you. A solution is being worked on.

-![gaming_layer](docs/gaming_layer.PNG)
+![gaming_layer](https://i.imgur.com/mPBElHc.png)

 ###1.2 Function Layer
 This is the function layer for German diacritics. It can be accessed via the `Fn` or by holding `Space` on the base layer.

-![function_layer](docs/function_layer.PNG)
+![function_layer](https://i.imgur.com/abpqBDE.png)




keyboards/satan/keymaps/iso_split_rshift/readme.md

@@ -31,6 +31,6 @@ in the default qwertz layout
 * Keymap has been based on TerryMathews' fork of Aqoush's fork of qmk-satan-rgb. [here](https://github.com/TerryMathews/qmk-satan-rgb/tree/master/keyboard/satan)
 * nice visualization of the layers [here](http://www.keyboard-layout-editor.com/#/gists/aba4e4396459ede85bc66a22cee88e48)
 * no-need-to-solder-on-chip picture:
-![no need to solder directly on the chip anymore](LEDpinSatan.jpg)
+![no need to solder directly on the chip anymore](https://i.imgur.com/AitpDoB.jpg)
 * special thanks to /u/TerryMathews  who suggested the pin PB2, so soldering
 directly on the atmega is not needed anymore. Happened on [reddit](https://www.reddit.com/r/MechanicalKeyboards/comments/4ghq9z/photos_satan_rgb60_w1976/d2k5tra)

keyboards/satan/readme.md

@@ -2,3 +2,6 @@ Satan GH60 keyboard firmware
 ======================

 TODO: to be updated.
+
+![controller](https://i.imgur.com/9vyRBoT.jpg)
+![power](https://i.imgur.com/pHMZHLP.jpg)

keyboards/xd60/readme.md

@@ -1,6 +1,6 @@
 # QMK Firmware for XIUDI's 60% XD60 PCB

-![Top View of a pair of XD60 Keyboard](./xd60.jpg)
+![Top View of a pair of XD60 Keyboard](https://i.imgur.com/3Jq2743.jpg)

 ## Quantum MK Firmware
 For the full Quantum feature list, see [the parent readme.md](/readme.md).
